Telecom & Communication Cable Assemblies
ISO/IATF certified custom cable assemblies for networking, broadcasting and data center environmentsSAISONIC began in 1992 as a small fiber-optic assembly maker. Over the past 30 years, we have grown into a respected manufacturer of high-quality, complex cable assemblies. Using our experience, we provide complete, custom wiring solutions for a wide range of telecom and communication needs.
Modern 5G technologies, data centers, and all-optical networks show that telecom cable assemblies are no longer simple connectors, but strategic components that carry data flows. Communication networks heavily depend on signal integrity, transmission speed, interference resistance, and long-term reliability, so a defective cable can cause instability and delays in data transmission.
SAISONIC specializes in designing and manufacturing high-performance, reliable cable assemblies for demanding telecommunication and data communication applications. We have expertise in fiber termination (polishing), assembly, and testing, with all products and processes fully compliant with UL, CE, and RoHS certifications. Our engineers keep track of the latest standards from organizations like IEEE and OIF, allowing us to provide practical advice and design solutions for your products.
-
Material
High-purity copper (OFC) and silver-plated copper help minimize high-frequency signal loss by improving surface conductivity.
-
Structure
Solid or stranded. Solid conductors provide better phase stability, while stranded conductors offer greater flexibility.
-
Function
Holds the inner conductor in place and keeps it centered inside the outer conductor. It also affects how much signal is lost and what the cable impedance is.
-
Material
Made of solid polyethylene (PE), Teflon (PTFE), or foamed polyethylene (Foamed PE). The foamed type has many air pockets, which help reduce signal loss.
-
Function
Acts as the signal return path and provides protection against electromagnetic interference.
-
Structure
- Braided shield: One or more layers of woven copper wires, offering flexibility and durability.
- Foil shield: Aluminum-polyester tape wrapping that gives high coverage but is less flexible.
- Combined shield: The common “foil + braid” design offers both full coverage and good flexibility. When used for demanding use, double or triple shields can be applied.
- Function: Provides mechanical protection and environmental resistance.
- Material: PVC, PE, low-smoke halogen-free flame-retardant polyolefin (LSZH), or polyurethane (PUR).
- LSZH materials are especially important for server rooms and indoor use, as they emit minimal smoke and no toxic gases when burned.
- RF Connectors: SMA, SMB, N-type, TNC, BNC, 7/16 DIN (used for base stations), etc.
- High-Speed Data Connectors: RJ45, SFP+, QSFP+, DAC (Direct Attach Cable), etc.
- Data Transmission Connectors: USB, Type-C, Micro USB, etc.
-
Custom USB Type-C Cable Assembly -
Custom USB 2.0 Cable Assembly -
Micro USB Cable Assembly -
2-in-1 USB Cable Assembly -
Flat Ribbon Cable Assembly -
Custom USB Assembly -
Telecom Cable Assembly -
Ethernet Cable Assembly -
Flat Ribbon Cable Assembly -
Flat Ribbon Cable Assembly -
Jumper Wires -
Jumper Wires -
Flexible Flat Cable (FFC) Assembly: FFC-0.5mm pitch -
Flexible Flat Cable (FFC) Assembly: FFC-1.0mm pitch -
Flexible Flat Cable (FFC) Assembly: FFC-1.25mm pitch -
Flexible Flat Cable (FFC) Assembly: FFC-2.54mm pitch -
Panel-Mount USB Cable Assembly -
Pogo Pin Magnetic USB Cable Assembly -
Right-Angle USB Cable Assembly -
Pogo Pin Magnetic USB Cable Assembly
SAISONIC brings real value to your business with over 30 years of experience in communication cable assemblies. We don’t just supply products — we help you succeed.
Our engineers use their technical skills and knowledge of production and quality standards to create reliable, practical, and compliant cable solutions. With decades of experience, we understand how to design and manufacture safe, durable cable assemblies you can truly depend on.
